Precise control of temperature
Uniform product quality
Simple durable design for easy and low maintenance
Want A Free Consultation
ZPD Series Rotary Vacuum Paddle Dryer Industrial Self-Cleaning Function Paddle Dryer
AIPAK ZPD series rotary vacuum paddle dryer is an innovation horizontal batch-type vacuum dryer.The moister of wet material will be evaporated by heat transmission.The stirrer with squeegee will remove material on hot surface and move in the container to form cycle flow.The evaporated moisture will be pumped by vacuum pump.
This rotary drum paddle dryer can dry raw materials from pharmaceutical industry,foodstuff industry,chemical industry and so on.It is suitable for pulpiness,paste-like mixture or powder raw material.It can be used to dry thermal sensitive raw material that having the requirement to be dried at lower temperature.And raw materials that are easy to oxidize or explode and have strong irritative or toxic.And raw materials that need to recover solvent.
FEATURE
1.Being adapted the big area heating way,its heat conducting area is large and its heat efficiency is high.
2.Being installed stirring in the machine,it makes raw material in cylinder form the state of continuous circle inside the cylinder,so the uniformity to be heated of raw material is raised greatly.
3.Being installed stirring in the machine,pulpinese,paste-like mixture or powder raw materials can be dried easy.
DATA SHEET
| ltem | type | |||||||
| Name | unit | ZPD-500 | ZPD-750 | ZPD-1000 | ZPD-1500 | ZPD-2000 | ZPD-3000 | ZPD-5000 |
| Working volume | L | 300 | 450 | 600 | 900 | 1200 | 1800 | 3000 |
| over in the cylinder | Mm | Φ600 x 1500 | Φ800 x 1500 | Φ800 x 2000 | Φ1000 x 2000 | Φ1000 x 2600 | Φ1200 x 2600 | Φ1400 x 3400 |
| tirring revolution | rpm | 7-6 | ||||||
| Power | kw | 4 | 5.5 | 5.5 | 7.5 | 11 | 15 | 22 |
| Design pressure of jacket | MPa | 0.3-0.8 | ||||||
| Pressure in the cylinder | Mpa | ‘-0.09~-0.096 | ||||||
| Non tho wapomnd amnou0m ot watir m rlato to thoe choacerots oet rw man in the tmopemnt rno ot oir inand or out Wt rermw poucts uneee -inghy. the tand parameterns wil b oxchanged, in does not announce in ldvance, pardon ! | ||||||||
