Easy to operate
Simple structure& convenient operation
High degree of automation

TDP-6 Single punch tablet press machine

AIPAK TDP-6 Single punch tablet press machine is a tablet device used to press various granular materials into round tablets or other special-shaped tablets. It is an ideal product suitable for trial production and small-scale production of tablets in scientific research institutes, schools, and pharmaceutical laboratories.

FEATURE

1.This machine has excellent performance, strong adaptability, convenient use, easy maintenance, small size and light weight, and it can be shaken by hand when there is no electricity.

2.This machine only installs a pair of die, the filling depth of the material and the thickness of the tablet can be adjusted.

3.It can meet the requirements of the pharmaceutical industry to compress various Chinese and Western medicine tablets and the requirements of other industries to compress various similar products. User welcome.

DATA SHEET

model	TDP-6
Maximum tablet pressure (kN)	60
Maximum tablet diameter (mm)	25
Maximum filling depth (mm)	16
Maximum tablet thickness (mm)	6
Production capacity (pieces/hour)	5000
Motor power (kw)	1.1
Dimensions (mm)	700500900
Host weight (kg)	140
