NJP-200 Full Automatic Capsule Filling Machine

NJP-200 Full automatic capsule filling machine is a full automatic hard capsule filling equipment with intermittent operation and hole plate filling.

This product is improved with its functionality ,bases on the original automatic capsule filling machine . And its technology content have reached advanced domestic level,.It is the ideal device filled capsules of drugs, with full compliance with GMP requirements.



FEATURE

  1. Touching-Screen, PLC program control panel with LCD.
  2. Capsule vacuum positioned mechanism to make the capsule qualified over 99%.
  3. Removable powder hopper for cleaning and easy auger adjustment easy to change fills weights.
  4. Easy speed selection and closed capsule length adjustment.
  5. Electrical Appliance control system approved to CE, and international standard.
  6. Quick and accurate change part set-up, easy to remove rotary table and ring carrier assembly.
  7. Fully enclosed dosing stations and rotating table for integration of the whole capsule filling plants.
  8. Large cam mechanism keeps the rotating table of mould together with the whole equipment running with balance, and completely guarantees the machine operating with highest precision and accuracy.

DATA SHEET

Model

NJP-200

NJP-400

Productivity

12000 capsules/Hour

24000 capsules/Hour

Size of Capsule

Capsules Size 00"-5" and safety capsule A-E

Total Power

3.7KW

Water Supply

500L/H,0.2-0.10Mpa

Dust Collector

160m³/H

Overall dimensions

720X680X1700MM

Weight

700KGS
