Easy to clean, can be disassemble without tools
PLC programmable control
Material contact parts are made of SUS304# stainless steel

Automatic Tea Protein Powder Filling Machine Spices Milk Coffee Powder Filling Machine

AIPAK APK-Q1-D protein powder filling machine is suitable for the powder like protein powder,medical powder, milk powder, coffee powder, starch, Chili powder,flour and etc.The contact material is 304 stainless steel.As the machine is dexterous and flexible, it is easy removal. There is no limit of packaged container. The protein powder filling machine is widely used with invariable materials and package-weight specifications.

APK-Q1-D Protein Powder Filling Machine Details:

APK-Q1-D Protein Powder Filling Machine Applications:

FEATURE

1.This is a automatic auger type can/bottles metering filling machine ,designed for metering and filling various dry powder into different rigid containers: can/bottle/jar etc.

2.The machine provides powder metering and filling functions.

3.Bottles and cans are introduced by conveyor belt combined with gating system.

4.There is a photo eye sensor for bottles detection so as to achieve bottle-fill ,no-bottle no-fill.

5.Automatic bottle positioning-filling-releasing,optional vibration and elevation.

6.Featured with compact design,stable performance,easy to operate and good cost performance.

DATA SHEET

Model	APK-Q1-D100	APK-Q1-D160
Dosing mode	Directly dosing by auger	Directly dosing by auger
Filling weight	1 - 500g	10 – 5000g
Filling Accuracy	≤ 100g, ≤±2%；100 – 500g, ≤±1%	≤ 500g, ≤±1%; >500g, ≤±0.5%
Filling Speed	15 – 40 bottles per min	15 – 40 bottles per min
Power Supply	3P AC208-415V 50/60Hz	3P AC208 - 415V 50/60Hz
Air Supply	6 kg/cm² 0.05m³/min	6 kg/cm² 0.05m³/min
Total power	1.2Kw	1.6Kw
Total Weight	160kg	300kg
Overall Dimensions	1500×760×1850mm	2000×970×2030mm
Hopper Volume	25L	50L
