DPP-150E Automatic Rotary Blister Packaging Machine

The product is specially designed for hospital dosage room, laboratory institute, health care product, middle-small pharmacy factory, and featured by compact machine body, easy operation, multi-function, stroke adjustable, long durability etc, it is suitable for the Alu-PVC package of medicine, food, electric parts etc. Aided forming Pre‐cutting Inspection and rejecting control systems. Print mark registration Automatic feeder.

FEATURE

1. It adopts the newest type high-power transmission mechanism to arrange the chain and drive the main driving shaft. The errors and noises of other gear wheel transmission can be avoided.
2. Imported controlling system is adopted; also it can be equipped with detecting and rejection function device for number of medicines according to the user's requirement.
3. It adopts photoelectrical controlling system to make PVC, PTP, Aluminum/Aluminum material to be automatically fed and waste side to be cut automatically to guarantee the Synchronous stability of over- length distance and multi stations.
4. It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade.
5.The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing.

DATA SHEET

Punches frequency

10-35times/min

Production capacity

1200-4200plates/hour( two plates one time)

Max. forming area and depth

130x100(standard thickness≤15mm) Max. depth 26mm

Stroke range

50-120mm( can be designed as per user’s required)

Standard plate size

80x57mm ( can be designed as per user’s required)

Clean compressed air

0.4∽0.6Mpa

Air compressed capacity

≥0.3m3/min

Total power supply

380V 50HZ 3.8kw

Main power

1.5KW

PVC hard film

(0.15∽0.5)×150mm

PTP Aluminum film

(0.02∽0.035)×150mm

Dialysis paper

(0.02∽0.035)×150mm

Mould cooling

Tap water or recycling water

Overall dimension

2315×635×1405mm(L×W×H)

Net Weight

820KG

Gross Weight

890KG

Overall Dimension

2500×800×1780mm(L×W×H)

Noise

<75dB
