APK-GM600Q Large Scale Gummy Making Machine Up to 600kg Gummys /hr
AIPAK APK-GM600Q large scale automatic gummy making machine is a continuous production line for gummy manufacturing process.The whole body is built with food grade stainless steel, total length of whole line approx 16-18 meters. It can manufacturing up to 600kg gummies per hour,which will be a great gummy manufacturing equipment for your huge production.
The APK-GM600Q automatic gummy making machine is designed with gelatin cooking and mixing system,depositing system,cooling system,delivery system and PLC control system.Your operator can use the PLC control panel to set up all data of feeding speed, filling volume, colors/flavors/acids dosage, heating time, cooling time etc. Which makes your gummy production more intelligent and easy.
With AIPAK APK-GM600Q automatic gummy making machine,you can make one or two colors gummies,and the gummy molds section of this machine adopts a modular design, you can produce different shapes and sizes of gummies by changing different molds.And AIPAK can offer other auxiliary equipment for this large scale gummy manufacturing equipment such as sugar &sand spraying machine, oil coating machine, drying trays, wax polishing pan to meet your various production needs.
FEATURE
- PLC control system
- LED control pannel for easy operation
- Dosing system for feeding precise addition of colors, flavors and acids
- Quick release mold with full plate demoulding
- Oil spraying system for giving the smooth of gummy molds to get an easier release
- Big production capacity up to 600kg per hour
- Chang-over gummy molds design of gummy making machine, for changing different molds to make different shape and size gummies
DATA SHEET
Model |
APK-GM80Q |
APK-GM150 |
APK-GM300 |
APK-GM450 |
APK-GM600 |
Capacity |
80 kg/h |
150kg/h |
300kg/h |
450kg/h |
600kg/h |
Candy weight |
As per the candy size |
||||
Depositing Speed |
25~35 n/min |
25-45n/min |
|||
Steam requirement |
80kg/h, 0.4-0.6MPa |
250kg/h, 0.5-0.8MPa |
300kg/h, 0.8-1.2MPa |
400kg/h, 1.2-1.6MPa |
500kg/h, 1.6-1.8MPa |
Compressed air requirement |
0.2m3/min, 0.4-0.6MPa |
0.2m3/min,0.4-0.6MPa |
0.2m3/min,0.4-0.6MPa |
0.25m3/mi,0.4-0.6MPa |
0.3m3/min, 0.4-0.6MPa |
Working condition |
Temperature 20℃-25℃;Humidity45-55% |
||||
Electric power needed |
55kw/380V |
65kW/380V |
75kW/380V |
80kW/380V |
85kW/380V |
Total Length |
8m |
16m |
18m |
18m |
20m |
Weight of machine |
2500kg |
3500kg |
4000kg |
4500kg |
5000kg |
